Located in the heart of Kuwait’s industrial activity in Safat, Sayed Steel is a trusted name for quality and reliability. We take pride in supplying premium ASTM A709-50W Corten steel sheet and plate, a specialized material designed to serve the region’s demanding infrastructure needs. Sourced from reputable mills, this high-strength, low-alloy steel is the go-to choice for projects where exceptional durability and longevity are paramount, standing up to the toughest environmental conditions.
Formulated as a low-carbon steel, the composition of A709-50W Corten includes copper, phosphorus, and chromium. This specific alloy mix allows it to form a unique, protective patina when exposed to weather cycles, which actually shields the material from further corrosion. Mechanically, it offers a minimum yield strength of 50 ksi, providing excellent load-bearing capacity while retaining good formability and weldability for versatile fabrication.
STANDARD: ASTM A709
THICKNESS: 6-100mm
WIDTH: 900-4800mm
LENGTH: 3000-12000mm
GRADES:50W,50WT,50WF
SERVICES: Welding, Forming, Thermal Cutting
| TYPE | THICKNESS (in) | MN (wt %) | C (MAX wt %) | S (MAX wt %) | NI (MAX wt %) | P (MAX wt %) | V (wt %) | SI (wt %) | CR (wt %) | CU (wt %) |
|---|---|---|---|---|---|---|---|---|---|---|
| B | 2.00 – 3.00 | 0.75 – 1.35 | 0.20 | 0.030 | 0.50 | 0.030 | 0.01 – 0.10 | 0.15 – 0.50 | 0.40 – 0.70 | 0.20 – 0.40 |
| A | 0.1875 – 2.00 | 0.80 – 1.25 | 0.19 | 0.030 | 0.40 | 0.030 | 0.02 – 0.10 | 0.30 – 0.65 | 0.40 – 0.65 | 0.25 – 0.40 |
| GRADE | THICKNESS (in) | ELONGATION IN 8″ 2) (MIN %) | TENSILE STRENGTH (MIN ksi) | YIELD STRENGTH 1) (MIN ksi) | ELONGATION IN 2″ 2) (MIN %) |
|---|---|---|---|---|---|
| 50WT | 0.1875 – 3.00 | 18 | 70 | 50 | 21 |
| 50W | 0.1875 – 3.00 | 18 | 70 | 50 | 21 |
| 50WF | 0.1875 – 2.50 | 18 | 70 | 50 | 21 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Sayed Steel is one of the most prominent manufacturers and suppliers of superior quality ASTM A709-50W Corten Steel Sheet and Plate in Safat, Kuwait. As experts in steel solutions, we supply a complete spectrum of products like Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our product range comprises Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Known for our reliable delivery and first-rate customer service, we are committed to supplying high-quality steel materials that guarantee durability and excellent performance in numerous industrial applications.
| GRADE | THICKNESS (in) | MIN LONGITUDINAL INDIVIDUAL VALUE 1) (ft-lbs) | MIN LONGITUDINAL AVERAGE ENERGY 1) (ft-lbs) | ZONE 2 TEST TEMP | ZONE 1 TEST TEMP | ZONE 3 TEST TEMP |
|---|---|---|---|---|---|---|
| 50WT | 2.01 – 3.00 | — | 20 | 40 oF | 70 oF | 10 oF |
| 50WT | 0.1875 – 2.00 | — | 15 | 40 oF | 70 oF | 10 oF |
| 50WF | 0.1875 – 2.00 | 20 | 25 | 40 oF | 70 oF | 10 oF |
| 50WF | 2.01 – 2.50 | 24 | 30 |
| GRADE | WIDTH (in) | THICKNESS (in) | LENGTH (in) |
|---|---|---|---|
| 50WT | 72 – 120 | 0.1875 – 3.00 | 240 – 1200 |
| 50W | 72 – 120 | 0.1875 – 3.00 | 240 – 1200 |
| 50WF | 72 – 120 | 0.1875 – 2.50 | 240 – 1200 |
The most prominent use of ASTM A709-50W is in constructing resilient bridges and highway structures, where its weathering properties and strength are invaluable. Its durability also makes it a superior choice for heavy vehicles and transmission towers that endure constant stress. Beyond pure function, the distinctive rustic appearance of the weathered patina is increasingly embraced in architectural designs for building facades, outdoor sculptures, and distinctive roofing, blending longevity with a unique aesthetic.
