Sayad Steel stands as a trusted name for quality and reliability in Safat, Kuwait. We are proud to supply premium Carbon Steel API X70 5L PSL 1 Pipes, engineered for demanding industrial applications. Known for their exceptional strength and durability, these pipes are the go-to choice for critical projects. Our commitment is to provide clients with products that meet the highest standards of performance and safety. When you partner with us, you choose a dependable supplier dedicated to supporting Kuwait’s industrial growth with superior materials and expert service.
Crafted from high-strength, low-alloy steel, these pipes feature a fine-grain microstructure achieved through precise thermal treatment. This composition delivers a robust yield strength, ensuring they can withstand intense pressure and stress. The alloying elements, primarily manganese, are carefully balanced to provide excellent toughness and resistance to deformation. This careful engineering makes the material exceptionally reliable for constructing vital infrastructure, offering peace of mind in even the most challenging operating environments.
| X70 LSAW / DSAW | 16’OD TO 54″ OD (8 MM TO 50 MM THK) |
| Grade of material | X70 / L485 (N, M, Q, R) |
| Standard | ISO 3183 L485/ API 5L X70 |
| API 5L X70 ERW and HFW | 1/2” NB – 24” NB |
| API 5L Gr X70 Seamless Pipe (OD) | 21.3 – 660mm ( Inch 1/2” – 26”) |
| X70 Steel SAW | 16″ – 100″ NB |
| API 5L X70 PSL1 Pipe end | Flanged Ends, Buttweld, Square Cut, Coupling, Pub Joints, Thread Cutting, Cut Grooves, Deburring, Squared Ends, Beveled End (BE), Vibrator Grinding, Socket, Grooved, Screwed, Chamfering, Plain end (PE), Threaded Ends (Male & Female) |
| Manufacturing process | Welded, Seamless, Longitudinally Submerged Arc Welded (LSAW), Electro Fusion Seam Welded (EFSW), Submerged Arc Welded (SAW), Cold Drawn Seamless (CDS), Horizontal Submerged Arc Welded (HSAW), Extrusion, Hot Finish Seamless (HFS), Electric Resistance Welded (ERW) |
| API 5L X70 Wall Thickness | SCH-XXS, SCH160, SCH-XS, SCH40, SCH-STD, SCH80 |
| Equivalent Standards | KS, AISI, ISO, BS, SS, EN, JIS, AWWA, CSA, GOST, SAE, GB, ANSI, NFA, ASTM, API, DIN, IS, UNI |
| PSL Level | |
| X70 Carbon Steel Pipe Length | DRL, SRL, 20FT, 40FT, Single Random Length (SRL), Double Random Length (DRL), and Fixed Length 5.8 Meter, 12.0 Meters (40FT), 6.0 Meters (20FT), 11.8 Meters, |
| Mass fraction, based upon heat and product analysis a | |||||||
| Carbon Steel PIPE | |||||||
| C | Mn | P | S | V | Nb | Ti | |
| maxb | max.b | min. | max. | max. | max. | max. | max. |
| 0.28e | 1.40e | – | 0.030 | 0.030 | f | f | f |
| Y.S | T.S | ELONGATION |
| Mpa(psi) | Mpa(psi) | |
| min | min | min |
| 485(70 300) | 570(82 700) | F |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| NB | DN | OD (inches) | API 5L X 70 Carbon Steel Seamless Pipe Schedule | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SCH 5 | SCH 10 | SCH 20 | SCH 30 | SCH 40 | SCH 60 | SCH 80 | SCH 100 | SCH 120 | SCH 160 | |||
| 3/4″ | 20 | 1.05 | 0.065 | 0.11 | x | 0.095 | 0.113 | x | x | 0.17 | x | 0.219 |
| 1″ | 25 | 1.315 | 0.065 | 0.11 | x | 0.114 | 0.133 | x | x | 0.2 | x | 0.25 |
| 1.1/2″ | 40 | 1.9 | 0.065 | 0.11 | x | 0.125 | 0.145 | x | x | 0.225 | x | 0.281 |
| 2″ | 50 | 2.375 | 0.065 | 0.12 | x | x | 0.154 | x | x | 0.25 | x | 0.344 |
| 2.1/2″ | 65 | 2.875 | 0.083 | 0.12 | x | x | 0.203 | x | x | 0.3 | x | 0.375 |
| 3″ | 80 | 3.5 | 0.083 | 0.12 | x | x | 0.216 | x | x | 0.35 | x | 0.438 |
| 4″ | 100 | 4.5 | 0.083 | 0.12 | x | x | 0.237 | x | x | 0.437 | x | 0.531 |
| 5″ | 125 | 5.563 | 0.109 | 0.12 | x | x | 0.258 | x | x | 0.5 | x | 0.625 |
| 6″ | 150 | 6.625 | 0.109 | 0.13 | x | x | 0.28 | x | x | 0.562 | x | 0.719 |
| 8″ | 200 | 8.625 | 0.109 | 0.15 | 0.25 | 0.277 | 0.322 | 0.406 | 0.593 | 0.718 | 0.812 | 0.906 |
| 10″ | 250 | 10.75 | 0.134 | 0.17 | 0.25 | 0.307 | 0.365 | 0.5 | 0.718 | 0.843 | 1.0 | 1.125 |
| 12″ | 300 | 12.75 | 0.165 | 0.18 | 0.25 | 0.33 | 0.406 | 0.5 | 0.843 | 1.0 | 1.125 | 1.312 |
Sayed Steel is a leading supplier of high-quality Carbon Steel API X70 5L PSL 1 Pipes products in Safat, Kuwait. We focus on steel solutions and offer a variety of products. This includes Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our products are Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. We are known for our good delivery and excellent customer care. We aim to provide strong and durable steel materials for many industrial uses. We work hard to meet high standards, making us a trusted partner for your steel needs.
These pipes are indispensable for constructing long-distance, high-pressure pipelines that transport oil and natural gas. Their superior strength makes them ideal for gathering lines, distribution systems, and major cross-country transmission projects. Beyond the energy sector, they are also used in structural applications, water treatment facilities, and in demanding industries like petrochemical plants. Essentially, wherever there’s a need for a tough, dependable pipeline that can handle high pressures and challenging conditions, API X70 pipes provide a proven and trusted solution.
Sayed Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Safat, Kuwait.
