For over the years, Sayed Steel in Safat, Kuwait has become a name synonymous with reliability, and our Carbon Steel EN 10083-2 Grade C22R Pipe is a perfect example. We are proud to supply this versatile steel conduit, which is engineered to excel in demanding environments. Its consistent quality and strength make it a trusted foundation for various industrial and structural projects. When you choose this product, you are selecting a commitment to performance and durability that our team stands behind completely.
This grade is defined by its balanced chemical composition, primarily consisting of carbon and manganese, which directly translate to its practical strength. The steel offers a good combination of toughness and wear resistance, allowing it to handle significant stress without deforming. This makes it readily weldable and formable, providing fabricators with the flexibility needed for complex specifications. It’s a material that truly works as hard as you do.
| Specification | Details |
|---|---|
| Material | EN 10083-2 Grade C22R Carbon Steel |
| Product | Seamless Pipes and Tubes |
| Carbon Content | Max 0.20% |
| Manganese Content | 0.50% – 1.40% |
| Characteristics | – Low-Cost: Cost-effective option for low-carbon steel pipes – Formability: Easy to form and shape – Surface Hardness: Not as hard as high carbon steel pipes, but can be – increased through carburizing |
| Standard | Manufactured as per EN 10083-2 specification |
| Commercial Reference | Referred to as CS (carbon steel) pipes or MS (mild steel) pipes |
| Carbon | Silicon | Manganese | Phosphorous | Sulphur | Molybdenum | Nickel | Chromium | Copper | Others |
| 0.17-0.24 | max 0.40 | 0.40-0.70 | 0.045 | 0.045 | max 0.10 | max 0.40 | max 0.40 | – | – |
| Yield Strength | Tensile Strength | Elongation A5 min | |||
|---|---|---|---|---|---|
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
|  |  | 430 | – | – | 24 |
| DIN | EN | BS | NFA | ASTM | ASME |
|---|---|---|---|---|---|
| DIN 17204 Grade Cm22 | EN 10083-2 Grade C22R | – | ASTM A519 Grade 1021 | ASME SA 519 Grade 1021 | – |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a trusted manufacturer and supplier of high-quality Carbon Steel EN 10083-2 Grade C22R Pipe products in Safat, Kuwait. Specializing in premium steel materials, we offer a comprehensive range, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Committed to reliable delivery and exceptional customer service, Jaxon Steel provides top-grade materials that ensure superior performance across various industrial applications. Trust Jaxon Steel for all your Carbon Steel EN 10083-2 Pipe needs.
| Execution | Size Range | OD Tolerance | Wall tolerance |
|---|---|---|---|
| Hot-rolled Tube | OD – 80 mmOD > 80 mmWall < 12 mmWall – 12 mm | ± 0.4 mm± 0.5 % of OD | ± 0.7 mm± (5 % x wallthickness + 0.1 mm |
| Hot-rolled peeled tube | All sizesWall < 12 mmWall – 12 mm | + 0.25/- 0 mm | ± 0.8 mm± (5 % x wall thickness+ 0.2 mm) |
| Cold Worked tubecold-rolled or cold-drawn | OD < 40 mmOD 40 – 80 mmOD > 80 Wall Thickness < 6 mm Wall Thickness6 – 8 mm Wall Thickness > 8 | + 0.30/- 0 mm*+ 0.35/- 0 mm*+ 0.40/- 0 mm* | ± 0.30 mm± 0.35 mm± 0.40 mm |
You will often find these pipes playing a crucial role in constructing mechanical components like gears, gears, and axles where dependable performance is non-negotiable. Beyond machinery, they are a common sight in general structural applications, frames, and various fixtures. Essentially, any project that requires a robust, no-nonsense steel that can be trusted to hold up under pressure is an ideal candidate for this versatile and dependable grade.
Sayed Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Safat, Kuwait.
