Sayed Steel, a trusted name in Safat, Kuwait, is pleased to deliver premium Carbon Steel IS 3589 Pipes, perfectly crafted to meet the demanding standards of modern industry. We understand that your projects require materials you can count on, which is why we ensure every pipe delivers exceptional performance for critical applications. This dedication to quality makes us a reliable partner for businesses seeking strength and durability in their essential infrastructure components.
These pipes are crafted from robust carbon steel and include carefully balanced elements like silicon and manganese to ensure strength. The material achieves a minimum tensile strength of 350 MPa and a yield strength of 220 MPa, providing excellent resistance to pressure and stress. This reliable combination of composition and mechanical properties makes these pipes exceptionally durable and suitable for demanding environments.
| Size in MM | 15 Nominal Bore to 150 Nominal Bore |
| Dimension & Tolerance | Dimensions IS: 3589 = 2004 / Equivalent to BS = 1985/ 1387 |
| Specifications | IS 3589 |
| Surface Finish | Black |
| Pipe Marking | All Pipe are marked as follows: Supplier or Manufacturer’s Name, Standard, Grade, OD, Thickness, Length, Heat Number |
| Features | High Strength, Corrosion Resistant, Deformability & High Toughness |
| Length | As per Client’s requirement |
| Nominal Bore | Nominal Bore | Outer Diameter | Light | Medium | Heavy | |||
| Thickness | Weight | Thickness | Weight | Thickness | Weight | |||
| MM | IN | MM | MM | Kg/Meter | MM | Kg/Meter | MM | Kg/Meter |
| 6 | 1/8″ | 10.32 | 1.80 | 0.361 | 2.00 | 0.407 | 2.65 | 0.493 |
| 10 | 3/8″ | 17.10 | 1.80 | 0.674 | 2.35 | 0.852 | 2.90 | 1.020 |
| 15 | 1/2″ | 21.43 | 2.00 | 0.952 | 2.65 | 1.122 | 3.25 | 1.450 |
| 20 | 3/4″ | 27.20 | 2.35 | 1.410 | 2.65 | 1.580 | 3.25 | 1.900 |
| 8 | 1/4″ | 13.49 | 1.80 | 0.517 | 2.35 | 0.650 | 2.90 | 0.769 |
| 25 | 1″ | 33.80 | 2.65 | 2.010 | 3.25 | 2.440 | 4.05 | 2.970 |
| 40 | 11/2″ | 48.40 | 2.90 | 3.250 | 3.25 | 3.610 | 4.05 | 4.430 |
| 50 | 2″ | 60.30 | 2.90 | 4.110 | 3.65 | 5.100 | 4.47 | 6.170 |
| 65 | 21/2′ | 76.20 | 3.25 | 5.840 | 3.65 | 6.610 | 4.47 | 7.900 |
| 80 | 3″ | 88.90 | 3.25 | 6.810 | 4.05 | 8.470 | 4.85 | 10.100 |
| 100 | 4″ | 114.30 | 3.65 | 9.890 | 4.50 | 12.100 | 5.40 | 14.400 |
| 125 | 5″ | 139.70 | ….. | …… | 4.85 | 16.200 | 5.40 | 17.800 |
| 150 | 6″ | 165.10 | …… | ……. | 4.85 | 19.200 | 5.40 | 21.200 |
| Wall Thickness | 7 Inch Nominal Bore 193.7 Kg/Meter | 8 Inch Nominal Bore 219.1 Kg/Meter | 10 Inch Nominal Bore 273 Kg/Meter | 12 Inch Nominal Bore 323.7 Kg/Meter | 14 Inch Nominal Bore 355.6 Kg/Meter | 16 Inch Nominal Bore 406.4 Kg/Meter | 18 Inch Nominal Bore 454 Kg/Meter | 20 Inch Nominal Bore 508 Kg/Meter |
| 9.53 | …… | 51.50 | 60.24 | 73.75 | 81.21 | 93.13 | 105.00 | 117.00 |
| 4.85 | 22.59 | 25.62 | 32.07 | 38.13 | …… | …….. | ……. | ……. |
| 5.20 | 24.17 | 27.43 | 34.34 | 40.84 | …… | …….. | …….. | …….. |
| 5.60 | 26.00 | 29.28 | 36.93 | 43.93 | 48.11 | …….. | ……… | ………. |
| 7.01 | 32.27 | 36.76 | 46.43 | 55.45 | 61.82 | 69.04 | …… | …… |
| 7.94 | ….. | 41.00 | 50.95 | 61.85 | 67.98 | 77.92 | 87.80 | ……. |
| 6.35 | 29.34 | 33.28 | 41.73 | 49.67 | 54.43 | 62.35 | 70.50 | 78.50 |
| 6.00 | 27.88 | 31.53 | 39.50 | 47.02 | 51.49 | 61.00 | 69.00 | …….. |
| 8.18 | …… | 42.56 | 53.42 | 65.12 | …… | …… | …… | …… |
| 12.70 | …… | ….. | …… | …… | 107.28 | 123.30 | 139.00 | 155.00 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a leading manufacturer and distributor of high-quality Carbon Steel IS 3589 Pipe in Safat, Kuwait. We offer premium steel materials and a comprehensive range of products, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our extensive inventory includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. With a strong commitment to timely delivery and exceptional customer service, we use only the finest raw materials to ensure superior performance for industrial applications with stringent requirements. Contact us today for all your Carbon Steel IS 3589 Pipe needs!
| Nominal Bore | Outside Diameter | Light Thickness Weight | Medium Thickness Weight | Heavy Thickness Weight | |||||
| Inch | MM | Inch | MM | MM | kg/Meter | MM | kg/Meter | MM | kg/Meter |
| 1/8 | 3 | 0.406 | 10.32 | 1.80 | 0.361 | 2.00 | 2.65 | 0.493 | |
| 1/4 | 6 | 0.532 | 13.49 | 1.80 | 0.517 | 2.35 | 0.407 | 2.90 | 0.769 |
| 3/8 | 10 | 0.872 | 17.10 | 1.80 | 0.674 | 2.35 | 0.852 | 2.90 | 1.02 |
| 3/4 | 20 | 1.094 | 27.20 | 2.35 | 1.410 | 2.65 | 1.580 | 3.25 | 1.90 |
| 1.1/2 | 40 | 1.906 | 48.40 | 2.90 | 3.250 | 3.25 | 3.610 | 4.05 | 4.43 |
| 1 | 25 | 1.312 | 33.80 | 2.65 | 2.010 | 3.25 | 2.440 | 4.05 | 2.97 |
| 1.1/4 | 32 | 1.656 | 42.90 | 2.65 | 2.580 | 3.25 | 3.140 | 4.05 | 3.84 |
| 1/2 | 15 | 0.844 | 21.43 | 2.00 | 0.952 | 2.65 | 1.122 | 3.25 | 1.45 |
| 2 | 50 | 2.375 | 60.30 | 2.90 | 4.110 | 3.65 | 5.100 | 4.47 | 6.17 |
| 2.1/2 | 65 | 3.004 | 76.20 | 3.25 | 5.840 | 3.65 | 6.610 | 4.47 | 7.90 |
| 6 | 150 | 6.500 | 165.10 | – | – | 4.85 | 19.20 | 5.40 | 21.2 |
| 3 | 80 | 3.500 | 88.90 | 3.25 | 6.810 | 4.05 | 8.470 | 4.85 | 10.1 |
| 4 | 100 | 4.500 | 114.30 | 3.65 | 9.890 | 4.50 | 12.10 | 5.40 | 14.4 |
| 5 | 125 | 5.500 | 139.70 | – | – | 4.85 | 16.20 | 5.40 | 17.8 |
From transporting water and oil to constructing vital industrial frameworks, the versatility of these pipes is unmatched. They are the go-to choice for engineers and builders in power plants, chemical processing, and large-scale irrigation projects. Their reliable performance under pressure makes them essential for creating the robust infrastructure that supports communities and drives industrial growth throughout the region. This adaptability ensures they meet the challenges of a wide array of demanding applications.
Sayed Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Safat, Kuwait.
