Sayed Steel, a trusted name in Safat, Kuwait, is your dedicated partner for top-tier steel solutions, including the reliable Carbon Steel JIS G3456 Pipe. We understand that the backbone of any great project is quality materials, which is why we ensure our pipes meet the most rigorous standards. From our yard to your site, we are committed to providing not just a product, but a foundation of strength and durability you can build upon with absolute confidence for your industrial and construction needs.
The Carbon Steel JIS G3456 pipe is defined by its specific carbon, manganese, and silicon composition, which gives it a solid balance of strength and workability. Its key mechanical properties include a guaranteed minimum tensile strength and a good yield point, ensuring it can handle significant pressure and structural loads. This combination makes the pipe both tough and reliable, capable of performing consistently under demanding conditions without compromising its integrity.
| Standards | JIS G3456 Carbon Steel Pipe |
|---|---|
| JIS G3456 Carbon Steel Seamless Pipe Size | 4 to 219mm W. T.: 0.5 to 20mm |
| JIS G3456 Carbon Steel Welded Pipe Size | 5.0 mm – 1219.2 mm |
| JIS G3456 Carbon Steel EFW Pipe size | 5.0 mm – 1219.2 mm |
| JIS G3456 Carbon Steel Tube Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| JIS G3456 Carbon Steel Pipe Schedule | SCH5, SCH10, SCH10S, SCH20, SCH30, SCH40, SCH40S, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| JIS G3456 Carbon Steel Seamless Tube Size | 3.35 mm OD To 101.6 mm OD |
| JIS G3456 Carbon Steel Welded Tube Size | 6.35 mm OD To 152 mm OD |
| Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| JIS G3456 Carbon Steel Tube wall thickness | 0.020″ –0.220″, (special wall thicknesses available) |
| Length | Single Random, Double Random, Standard & Cut length Pipe & Tube |
| Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
| Form | Round, Hydraulic, ‘U’ bent or Hollow,LSAW, Boiler, Straight Pipe, Clad Pipe, Rectangular, Square Pipe Etc |
| Type | Welded, Seamless, ERW, EFW, Fabricated Pipe, ‘U’ bent or Hollow, Hydraulic, LSAW, Boiler, Straight Tube, Tube Coil, Round, Rectangular, Square Tube etc |
| End | Plain End, Beveled End, Treaded Pipe & Tube |
| Marking | All JIS G3456 Carbon Steel Pipe are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| Application | Oil Pipe & Tube, Gas Pipe & Tube, Fluid Pipe & Tube, Boiler Pipe & Tube, Heat exchanger Tube |
| Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| Test Certificate | Manufacturer Test Certificate Laboratory Test Certificate from Govt. Approved Lab. Under Third Party Inspection |
| Grade | C | Si | Mn | P | S |
| JIS G3456 STPT370 | ≤ 0.25 | 0.10-0.35 | 0.30-0.90 | ≤ 0.035 | ≤ 0.035 |
| JIS G3456 STPT410 | ≤ 0.30 | 0.10-0.35 | 0.30-1.00 | ≤ 0.035 | ≤ 0.035 |
| JIS G3456 STPT480 | ≤ 0.33 | 0.10-0.35 | 0.30-1.00 | ≤ 0.035 | ≤ 0.035 |
| Grade | Tensile Property (N/mm2) | Yield Point or Yield Strength (N/mm2) | Elongation (%) | |||
| NO. 11 Sample; NO. 12 Sample | NO. 5 Sample | NO. 4 Sample | ||||
| Longitudinal | Transverse | Longitudinal | Transverse | |||
| JIS G3456 STPT370 | ≥ 370 | ≥ 215 | ≥ 30 | ≥ 25 | ≥ 28 | ≥ 23 |
| JIS G3456 STPT410 | ≥ 410 | ≥ 245 | ≥ 25 | ≥ 20 | ≥ 24 | ≥ 19 |
| JIS G3456 STPT480 | ≥ 480 | ≥ 275 | ≥ 25 | ≥ 20 | ≥ 22 | ≥ 17 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is one of the prominent manufacturers and suppliers of high-quality Carbon Steel JIS G3456 Pipe in Safat, Kuwait. Being a company of premium steel material, we have a comprehensive product range in the form of Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our wide inventory list consists of Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. With commitments to time-to-market delivery and high quality of customer service, Jaxon Steel assures to deliver high-quality raw materials for better performance in any demanding industrial applications. Contact us today at Jaxon Steel to order all of your Carbon Steel JIS G3456 Pipe needs.
| Type | Allowable Deviation of Outer Diameter | Allowable Deviation of Wall Thickness | |||
| Hot-Working Seamless Steel Pipe | ＜50 mm | ± 0.5 mm | ＜ 4 mm ≥ 4mm | ± 0.5 mm ±12.5% | ≤ 20% of thickness |
| ≥ 50mm~＜160mm | ± 1% | ||||
| ≥ 160mm~≤ 200 mm | ± 1.6 mm | ||||
| ≥ 200 mm | ± 0.8% | ||||
| For ≥350 mm ones, we can measure according to the perimeters. Allowable deviation is ± 0.5%. | |||||
| Cold-Working Steel Seamless Pipe and Electric-Resistance Welded(ERW) Steel Pipe | ≤ 40 mm | ± 0.03 mm | ＜ 2 mm ≥ 2 mm | ± 0.2 mm ± 10 | |
This versatile pipe finds its purpose in a wide range of essential applications. It is commonly used for transporting water, oil, and gas in pipeline systems, and is a fundamental component in structural frameworks for buildings and industrial plants. You will also find it in general machinery parts and various construction projects where a dependable, pressure-resistant conduit is required. Its adaptability makes it a go-to choice for engineers and contractors across numerous sectors.
