Sayed Steel, a trusted name in Safat’s industrial landscape, takes pride in providing robust and reliable steel solutions. We are your dedicated source for high-strength HB 400 Sheets and Plates, materials engineered to meet the most demanding projects. Our team understands that the foundation of any great structure or machine is quality materials, which is why we ensure our HB 400 products offer the exceptional durability and performance your work requires, supporting Kuwait’s growing infrastructure and manufacturing sectors with unwavering strength.
The HB 400 grade signifies a specific level of hardness and strength, achieved through a carefully controlled composition and manufacturing process. This results in sheets and plates that possess superior mechanical properties, including high tensile strength and excellent resistance to abrasion and impact. Essentially, this material is built to withstand significant wear and tear over time, maintaining its integrity under heavy loads and in challenging environments, making it a fundamentally tougher option than standard steel plates.
Width:Â 500-3000mm
Thickness :Â 3-130mm
Length:Â 1000-12000mm
Heat Treatment:Â N, Q+T
Surface Paint:Â EP, PE, HDP, SMP, PVDF
| Hardened 400 Chemical Composition (%) | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Plate | C | Si | Mn | P | S | Cr | Ni | Mo | B | CEV | CET |
| thickness mm | max % | max % | max % | max % | max % | max % | max % | max % | max % | typv | typv |
| 3- 6 | 0.15 | 0.70 | 1.60 | 0.025 | 0.01 | 0.50 | 0.25 | 0.25 | 0.004 | 0.41 | 0.28 |
| 3-（8） | 0.15 | 0.70 | 1.60 | 0.025 | 0.01 | 0.30 | 0.25 | 0.25 | 0.004 | 0.33 | 0.23 |
| 8 – 20 | 0.15 | 0.70 | 1.60 | 0.025 | 0.01 | 0.50 | 0.25 | 0.25 | 0.004 | 0.37 | 0.27 |
| （20）-32 | 0.18 | 0.70 | 1.60 | 0.025 | 0.01 | 1.00 | 0.25 | 0.25 | 0.004 | 0.48 | 0.29 |
| （32）-45 | 0.22 | 0.70 | 1.60 | 0.025 | 0.01 | 1.40 | 0.50 | 0.60 | 0.004 | 0.57 | 0.31 |
| （45）-51 | 0.22 | 0.70 | 1.60 | 0.025 | 0.01 | 1.40 | 0.50 | 0.60 | 0.004 | 0.57 | 0.38 |
| （51）-80 | 0.27 | 0.70 | 1.60 | 0.025 | 0.01 | 1.40 | 1.00 | 0.60 | 0.004 | 0.65 | 0.41 |
| （80）-130 | 0.32 | 0.70 | 1.60 | 0.025 | 0.01 | 1.40 | 1.50 | 0.60 | 0.004 | 0.73 | 0.48 |
| Mechanical properties of Hardened 400 | |||||
|---|---|---|---|---|---|
| Grade | Mechanical Property | Charpy V Impact Test | |||
| HARDOX 400 | Yield | Tensile | Elongation | Degree | longitudinal |
| Min Mpa | Mpa | Min % | -40 | J | |
| 1000 | 1250 | 10 | 45 | ||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Thickness (mm) | Product | Hardness Range (HBW) |
|---|---|---|
| 2.5 – 6.4 | Cut Lengths | 360 – 420 |
| 5 – 15 | Heavy Plates | 360 – 420 |
| 15- 30 | Heavy Plates | 360 – 450 |
| 30 – 60 | Heavy Plates | 360 – 480 |
The uses for these high-strength sheets and plates are extensive, making them indispensable in heavy industries. They are perfectly suited for fabricating equipment that faces constant friction, such as dump truck liners, heavy machinery platforms, and crushing components. You’ll also find them in construction for reinforcing high-stress areas, in mining for hoppers and chutes, and across various industrial applications where maximizing the lifespan of equipment is a top priority. They are the go-to choice for projects that simply cannot afford to compromise on material strength.
Sayed Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Safat, Kuwait.
