Sayed Steel is a prominent steel manufacturer and supplier of high-grade steel products in Safat, Kuwait, with expertise in SAE 1045 steel plates and sheets. With its exceptional strength, durability, and machinability, SAE 1045 steel is well-suited for numerous industrial uses, such as construction, engineering, and manufacturing. At Sayed Steel, we are dedicated to providing precision-engineered steel solutions that are up to industry standards, guaranteeing reliability and performance. Committed to quality and customer satisfaction, we offer best-quality steel products designed to suit various needs.
SAE 1045 steel plate and sheet is a medium carbon steel with an about 0.43-0.50% carbon, 0.60-0.90% manganese, and incidental amounts of sulfur and phosphorus. It contains good mechanical properties such as 570-700 MPa tensile strength, 300 MPa yield strength, and 170-210 HB hardness. It has excellent strength, satisfactory weldability, and better machinability. It is best suited for shafts, gears, and structural parts demanding toughness and resistance to wear, and hence can be used in many industrial applications.
| Specification | ASTM A830 AISI 1045, SAE 1045, |
| Grade | SAE J403 Grade 1045 |
| Condition | hot rolled or normalized |
| Width | Â 200 to 2000mm |
| Thickness | Â 6 to 800mm |
| Length | 2000 to 6000mm |
| Heat treated method | By flame or induction |
| MN | FE | S | C | P |
|---|---|---|---|---|
| 0.60 – 0.90% | 98.51 – 98.98% | ≤ 0.050% | 0.420 – 0.50% | ≤ 0.040% |
| MECHANICAL PROPERTIES | Â | Â |
|---|---|---|
| Â | Metric | Imperial |
| Tensile Strength, Ultimate | 565 MPa | 81,900 PSI |
| Tensile Strength, Yield | 310 MPa | 45,000 PSI |
| Modulus of Elasticity | 200 GPa | 29,000 KSI |
| Hardness, Brinell | 163 | 163 |
| Elongation at Break (in 50 mm) | 16.0% | 16.0% |
| Bulk Modulus (Typical for Steel) | 140 GPa | 20,300 KSI |
| Poissons Ratio | 0.290 | 0.290 |
| Shear Modulus | 80 GPa | 11,600 KSI |
| Grade | EU EN | DIN,WNr | JIS | AFNOR | BS | GOST | ISO | UNS |
| 1045 | C45E (1.1191) | Ck45 | S45C | XC45 XC48H1 | 080M46 CFS8 | 45 | C45E4 | G10450 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Length x Width | Thickness |
|---|---|
| mm | mm |
| 2000 x 1000 | 0.8 |
| 2440 x 1220 | 1.0 |
| 2500 x 1250 | 0.9 |
| 2500 x 1250 | 0.8 |
| 2000 x 1000 | 1.20 |
| 2000 x 1000 | 1.0 |
| 2000 x 1000 | 0.9 |
| 1830 x 1220 | 1.0 |
| 2500 x 1250 | 1.20 |
| Thickness | Length x Width | Mass per Sq m |
|---|---|---|
| mm | mm | Kg/m2 |
| 30.00 | 2000 x 1000 | 235.50 |
| 30.00 | 4000 x 2000 | 235.50 |
| 30.00 | 2500 x 1250 | 235.50 |
| 30.00 | 5000 x 2500 | 235.50 |
| 30.00 | 3000 x 1500 | 235.50 |
| 30.00 | 5000 x 1250 | 235.50 |
| 40.00 | 2000 x 1000 | 314.00 |
| 32.00 | 2000 x 1000 | 251.20 |
| 30.00 | 10000 x 2500 | 235.50 |
| 30.00 | 6000 x 2500 | 235.50 |
| 32.00 | 2500 x 1250 | 251.20 |
| 32.00 | 3000 x 1500 | 251.20 |
| 32.00 | 5000 x 2500 | 251.20 |
| 32.00 | 4000 x 2000 | 251.20 |
| 35.00 | 3000 x 1500 | 274.75 |
| 35.00 | 4000 x 2000 | 274.75 |
| 35.00 | 2500 x 1250 | 274.75 |
| 40.00 | 2500 x 1250 | 314.00 |
| 40.00 | 3000 x 1500 | 314.00 |
| 40.00 | 4000 x 2000 | 314.00 |
SAE 1045 steel plate and sheet, a medium carbon steel, finds extensive use in the applications where there is a need for strength, toughness, and resistance to wear. It finds extensive use in gears, shafts, axles, crankshafts, bolts, and forged parts. It is also suitable for industrial equipment, hydraulic clamps, construction machinery, and farm implements. Having good machinability and weldability, it also finds use in structural components and automotive components. Its resistance to impact and high hardness also render it appropriate for challenging manufacturing and engineering applications.
Sayed Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Safat, Kuwait.
